| General |
Brand: FOSSiBOT
Type: Smartphone
Model: F102
Color: Red |
| Operating System |
Android 13.0 |
| CPU |
Model: MT6789V/WB, helio G99
Feature: octa-core
Framework: 2*Cortex -A76@ 2.2GHz; 6*Cortex -A55@2.0GHz
Technology: 6nm |
| GPU model |
ARM G57 MC2 Manhattan 3.0: >36fps |
| Video |
Video encode: HEVC/VP9 decoder 2560*1440@30 fps/60Mbps
Video decode: MPEG |
| Network |
Network: GSM, GPRS, EDGE, WCDMA, LTE
Frequency:
GSM: 850/900/1800/1900MHz
3G: B1/B2/B4/B5/B8
4G: B38/B39/B40/B41/B1/B2/B3/B4/B5/B7/B8/B12/B17/B18/B19/B20/B25/B26/B28A/B28B/B66/B71
EDGE/GPRS: Support |
| Storage |
Memory Type: RAM12GB ROM256GB, up to 8GB RAM expansion
SIM card type: Nano SIM Nano SIM OR Nano SIM TF
Memory card type: T-flash card
Expanded memory: Up to 1TGB |
| Front Camera |
Front Camera: 32MP
Sensor: Sony IMX616
Sensing area: 1/2.76inch
Pixel area: 6528*4896
Aperture: 2.0±5%
Optical Image Stabilization: N/A
Sensor type: 79°
PDAF: N/A
Flash LED: N/A
Software function: Video, Picture, Beauty, Mono, Dynamic photo, face unlock |
| Rear Camera |
Rear Camera: Rear triple camera 108MP 20MP infrared night vision 5MP macro
Sensor: Main: Samsung S5KHM2SP03, Night Vision: Sony IMX350, Macro: HI-556
Sensing area: 1/1.52inch, / , 1/4inch
Pixel area: 3024*4032, 5184*3880, /
Aperture: F1.79 /- 5%, F 2.2±5%, F2.2
Optical Image Stabilization: Support, N/A, N/A
Sensor type: 82°, 78°, 78°
PDAF: PDAF/AF, AF, FF
Flash LED: Support
Camping light: Support
Software function: Video, Picture, Beauty, Mono, Bokeh, pro, Portrait, dynamic photo, panorama, slow motion, macro, scan code |
| Display |
Size & technology: 6.58" FHD IPS screen
Type: TFT-in-cell LCD
Resolution: DOTS: 1080*RGB*2408
Aspect Ratio: 20/9
Screen-to-body ratio: 84%
Brightness: 400cd/m² (MIN), 450cd/m² (TYP) |
| Transmission Function |
Navigation: GPS, Glonass, Beidou, Galileo, QZSS
WiFi: 2.4G 802.11b/g/n, 5G 802.11a/n
Bluetooth: BT 5.2
FM: Support / Plug in the earphone cable to put it outside
OTG: Support
NFC: Support |
| Sensor |
Hall switch: N/A
Infrared remote control: N/A
HotKnot: N/A
G-sensor: Support (3 shaft)
Proximity sensor: Support
Ambient light sensor: Support
Compass (magnetic): Support
Geomagnetism: Support
Gyroscope: Support |
| Unlock Method |
Fingerprint ID: Support |
| Hardware Features |
Wireless charge: N/A
Hard coulometer: Support
Rapid Charge: Support
Sound Amplifier: Stereo dual speakers |
| Touch Panel |
Panel technology: In-cell multi-touch
IC: NT36672CH or ICNL9922C
Sensor technology: capacitive
Material: Dragon Trail
Fitting method with Display: full fit |
| Physical Buttons |
Power button: Support
Volume button: Support
Camping light switch key: Support
Custom key button: Support |
| Virtual Buttons |
Home button home: Support
Menu button: Support
Return button: Support |
| Electric Acoustic Devices |
Speaker: Double 1217 BOX
Motor: 0827 Welded wire motor
Receiver: 0809 shrapnel type (IP68 waterproof level)
Mic: Silicon wheat
Notify light: Support
Button LED: N/A |
| Port |
Headphone port: TYPE-C
Charger interface: TYPE-C |
| Battery |
Capacity: non-removable, label capacity: 16500mAH
Fully charge and discharge frequency: 400 times
Material: Polymer
Voltage: 4.45V
Discharge coefficient: 0.5C
Battery density ratio: 647 |
| Housing |
Housing structure: Two-color injection molding
Housing material: Two-color injection molding material for the bottom shell in-mold injection molding of aluminum and titanium hardware brackets |
| System function |
System navigation: Gesture navigation, 3-button navigation
Smart gesture: Support
Air gesture: N/A
Communication somatosensory: N/A
System somatosensory: N/A
FOTA upgrade OTA: Support
Supported languages: English, Spanish, Portuguese (Brazil), Portuguese (Portugal), Italian, German, French, Russian, Arabic, Malay, Thai, Greek, Ukrainian, Croatian, Czech, Simplified Chinese, Traditional Chinese. (It has updated 48 languages) |
| Entertainment features |
Video playback: Support AVI, MP4, WMV, RMVB, MKV, MOV, ASF, RM, FLV, and other video formats, up to 720p / 30fps
Video produce: Highest support 720p@30fps video shooting
Audio player: Support MP3, M4A, AAC, MKA, AMR, and other video formats / supports lossless format: ALAC(Apple Lossless), FLAC, APE, WAV
Graphic format: Support JPEG, BMP, GIF, PNG etc.
Game: Support
Applications: Support |
| Other software |
Market: Support
Share: Support
Software Toolbox: Compass, Magnifier, Gradienter, Flashlight, Pic Hanging, Sound Meter, Height Measure, Pedometer, Warning, Protractor, Plumb bob, Mirror
Privacy Protection, Visitor Mode: Support |
| Weight & Size |
Product Weight: 495g
Package Weight: 835g
Product Size(L x W x H): 172.3*82.6*25.6mm
Package Size(L x W x H): 205*178*40.5mm |
| Package Contents |
1 x Smartphone
1 x Charger
1 x Type-C cable
1 x User manual |
