Door Sensor (mFi-DS) is a magnetic switch sensor. It is designed to detect open entry points, such as doors, windows, or other physical enclosures.
For use with mFi mPort hardware and mFi Controller software (included with the mFi mPort).
|
mFi-DS
|
|
Dimensions
|
50 x 9.5 x 7.7 mm (Magnet)
50 x 9.5 x 7.7 mm (Switch)
|
|
Weight
|
350 g (Magnet and Switch)
|
|
Contact Form
|
Form A (SPST )
|
|
Maximum Rating
|
1.0A @ 28VDC
|
|
Initial Contact Resistance
|
0.3 $191 Maximum
|
|
Operating Range
|
20 mm ( Typical)
|
|
Wiring
|
Screw Terminal
|
|
Mounting
|
Adhesive or Screws (Included)
|
|
Operating Temperature
|
-10 to 60° C
|
|
Operating Humidity
|
|
