Highlights
Ultra-High Precision
Achieve outstanding ±0.1mm positioning accuracy and 0.01mm repeatability. The rigid motion system ensures stable, smooth operation without vibration or step loss.
Industrial-Grade Intelligent Control
Equipped with the self-developed ATOMSTACK 4AXIS Intelligent Controller V1.0, supporting 24/7 continuous work, 4-axis linkage, 4-point centering, precision calibration, and software limit protection for safer, smarter machining.
High-Strength & High-Speed Motion System
Built with MGH12 linear guides and dual-nut lead screws, the C4 Pro reaches up to 2000mm/min engraving speed — completing a brass seal in just 15 minutes with high accuracy and rigidity.
Multi-Material Compatibility
The 12,000 RPM high-power spindle handles wood, aluminum, brass, acrylic, PVC, POM, and PCB with ease — perfect for woodworking, PCB production, and metal engraving.
Industrial Offline Control
Comes with a professional handwheel controller, allowing you to monitor and adjust spindle position in real time without a computer for a true industrial experience.
One-Click CNC/Laser Mode Switching
Easily switch between CNC and laser engraving modes. Supports hybrid workflows for laser engraving followed by CNC cutting.
Specification
| General |
Brand: ATOMSTACK
Type: CNC Router Machine
Model: C4 Pro
Color: Black & Red
|
| Specification |
Output Mode/Power: 200W Spindle (Upgradable to 500W Spindle or 20W Blue Laser Module)
Engraving Speed: 2000 mm/min
Laser Engraving Speed: 12,000 mm/min
Positioning Accuracy: ±0.1 mm
Repeatability: 0.01 mm
Motion Structure: Linear Guide High-Precision Dual-Nut Lead Screw
Working Area: 420 × 420 mm (Recommended: 400 × 400 mm)
Limit Mode: Software Limit Control (CNC Soft Limit)
Control Method: PC Software / Offline Controller
Tool Setting Method: Electric or Manual Tool Setting
4-Point Centering: Supported
Software Compatibility: Candle, UGS, ioSender, LightBurn (for Laser), etc.
Upgradeable Accessories: 4th Rotary Axis, Dust Collector, 500W Spindle Kit, 40W Laser Module Kit, Metal Clamps, etc.
Compatible Materials: Wood, MDF, Soft Aluminum, Bamboo, Cardboard, Cork, Slate, Jade, PCB Board, Medium-Density Board, Soft Metals, and more. |
| Weight & Size |
Product Weight: 26.75kg
Package Weight: 26.8kg
Product Size(L x W x H): 63.1x42.3cm
Package Size(L x W x H): 80x73x30cm |
| Package Contents |
1 x X-axis Assembly
1 x Base
1 x Magenta Component
1 x 80/200W Component
4 x Cylindrical Head Screws
4 x Pressure Plates
4 x Wing Nuts
4 x M6*50 Screws
4 x M6*70 Screws
8 x M5*8 Screws
8 x M3*6 Screws
1 x H2 L-shaped Hex Key
1 x H2.5 L-shaped Hex Key
1 x H3 L-shaped Hex Key
1 x H5 L-shaped Hex Key
1 x HDMI Cable
1 x Control Handle
1 x Handle Bracket
1 x Power Adapter
1 x Power Cable
1 x Data Cable
1 x Engraving Tool Set
1 x Tool Setting Block
2 x Open-end Wrenches
1 x Brush
1 x Instruction Manual
1 x Baffle
1 x Certificate of Conformity
2 x Desiccants
|
