SPECYFIKACJA
Rama: KELLYS THEOS R-series - advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / Think Link® suspension system, 130 mm rear travel, integrated removable battery, 1. 8“ tapered HT, post mount 203 mm, mullet 29 / 27. 5+ wheelset, 12x148 mm Boost thru axle
Rozmiary ram: S / M / L
Silnik:
PANASONIC GX Ultimate, 95 Nm, 36 V
Przełącznik: PANASONIC
Wyświetlacz licznika: PANASONIC Bluetooth® 5. 0 navigation Side Color Display
Akumulator: KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ
Widelec:
ROCK SHOX Zeb Select (29) Boost, 150 mm, DebonAir+ / Charger RC / Maxle Stealth 15 mm thru axle
Amortyzator tył: ROCK SHOX Deluxe Select+ RT, DebonAir+ / Open-Threshold (210x55 mm)
Stery: ACROS 1. 8 tapered semi-integrated
Korby: MIRANDA Miranda (34T) - length 170 mm
Manetki:
SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV)
Przerzutka tył: SHIMANO Deore XT Linkglide M8130 (direct mount)
Ilość biegów: 11
Kaseta: SHIMANO Linkglide CS-LG600-11 (11-50T)
Łańcuch: SHIMANO Linkglide CS-LG500 (122 links)
Hamulce: SHIMANO SLX M7120 Hydraulic Disc
Tarcze hamulcowe:
SHIMANO RT30 203 mm front / EM300 203 mm rear
Dźwignie hamulcowe: SHIMANO SLX BL-M7100
Oś: thru axle ROCK SHOX Maxle Stealth 15x110 mm front / Mr. Control 12x177 mm rear
Koła: NOVATEC M30 622x30 front / NOVATEC M35 584x35 Center Lock rear (15x110 mm / 12x148 mm)
Opony:
SCHWALBE Magic Mary Evo Super Trail 62-622 (29x2.40) Tubeless Easy, ADDIX Ultra Soft, folding, front / SCHWALBE Big Betty Evo Super Trail 65-584 (27.5x2.60) Tubeless Easy, ADDIX Soft, folding, rear
Wspornik kierownicy: KLS Alm/En 50 - diam 28. 6 mm / bar bore 31. 8 mm / length 60 mm
Kierownica: KLS Alm/En 70 RiseBar - diam 31.
8 mm / rise 25 mm / width 780 mm
Chwyty: KLS Poison OneLockon
Sztyca: LIMOTEC A1 Remote Telescopic - diam 30. 9 mm / length 445 mm, travel 150 mm
Siodło: fi´zik Taiga S-alloy rails
Pedały:
plastic
