(1)Opis i specyfikacja
Highlights
Powerful & Versatile
Delivers 2000W output power, ideal for residential, small industrial, and commercial use, with wide compatibility, excellent low-light performance, and flexible system design.
High Efficiency & Power Maximization
Achieves up to 96% efficiency with 4 independent MPPTs, enabling precise monitoring to maximize power generation.
Durable & Reliable
Built with IP67 protection, ensuring stable and reliable operation even in harsh environments.
Smart Monitoring & Control
Equipped with an intelligent Wi-Fi module for real-time monitoring, fault detection, and dynamic power adjustment from 5% to 100%.
Safety & Compatibility
Supports a maximum DC voltage of 60V and input current of 15A, fully compatible with mainstream PV modules.
Easy Installation & Long Lifespan
Features plug-and-play installation, a 25-year design life, a 10-year product warranty, and an integrated smart communication system.
Specification
| General |
Brand: LIONSHEE |
| Specification | Recommended PV Module Power: 280W–650W Start-up Voltage: 20V MPPT Voltage Range: 28V–55V Max. Input Voltage: 60V Max. Input Current: 15A × 4 Max. DC Short-Circuit Current: 19A Number of MPPTs: 4 Rated Output Power: 2000W Nominal Output Voltage: 230V Extended Output Voltage Range: 184V–253V Nominal Output Current: 8.7A Nominal Frequency / Range: 50Hz / 45–55Hz Power Factor: >0.99 (default) Total Harmonic Distortion (THD): <3% Max. Units Per Branch: 3 Peak Efficiency: 96.0% CEC Efficiency: 95.5% Static MPPT Efficiency: 99.5% Night-time Power Consumption: <50mW Ambient Temperature Range: -40℃ ~ 65℃ Enclosure Rating: IP67 Cooling: Natural Convection (No Fans) Isolation Type: High-Frequency Transformer Communication: Wi-Fi Energy Management: Solarmon Online Platform Warranty: 10 Years Standard |
| Weight & Size | Product Weight: 7 kg Package Weight: 8 kg Product Size(L x W x H): 31.2x30.1x4.3 cm Package Size(L x W x H): 52x47x6 cm |
| Package Contents |
1 x Micro Inverter |
