SPECYFIKACJA
Rama: KELLYS TAYEN R-series - advanced robotic welded 6-series aluminium alloy / Designed & manufactured in EUROPE / integrated removable battery, 1. 5“ tapered HT, 12x148 mm Boost thru axle
Silnik: PANASONIC GX Ultimate, 95 Nm, 36 V
Akumulator: KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by Kellys-BMZ
Przełącznik:
PANASONIC
Wyświetlacz licznika: PANASONIC color LCD side display
Widelec: ROCK SHOX 35 GOLD RL (29) Boost, 120 mm, DebonAir / Motion Control / Maxle Stealth 15 mm thru axle
Korby: MIRANDA Delta (36T) - length 170 mm
Przerzutka tył: SHIMANO Deore XT M8100 (direct mount)
Manetki:
SHIMANO Deore SL-M6100-IR Rapidfire Plus (I-Spec EV)
Ilość biegów: 12
Kaseta: SHIMANO CS-M6100-12 (10-51T)
Łańcuch: SHIMANO CN-M6100 (122 links)
Hamulce: SHIMANO Deore MT420 Hydraulic Disc
Dźwignie hamulcowe: SHIMANO Deore BL-M4100
Tarcze hamulcowe:
180 mm front / 180 mm rear
Piasty: SHIMANO MT400-B / Deore MT410-B Disc Center Lock (15x110 mm / 12x148 mm / 32 holes)
Obręcze: KLS Valor 3 Disc 622x30 (32 holes)
Szprychy: stainless steel black
Opony: SCHWALBE Nobby Nic Performance 60-622 (29x2.35) ADDIX, folding
Stery:
FSA 1. 5 semi-integrated
Oś thru axle: ROCK SHOX Maxle Stealth 15x110 mm front / NOVATEC 12x181 mm rear
Wspornik kierownicy: KLS Alm/En 50 - diam 28. 6 mm / bar bore 31. 8 mm / length 45 mm
Kierownica:
KLS Active RiseBar - diam 31. 8 mm / rise 18 mm / width 700 mm
Chwyty: KLS Poison OneLockon
Sztyca: LIMOTEC A1 Remote Telescopic - diam 30. 9 mm / length 445 mm, travel 150 mm
Siodło:
SELLE ROYAL Vivo
Pedały: plastic
Rozmiary ram: M / L
