SPECYFIKACJA
Rama: KELLYS THEOS 2024 F100 Carbon-Aramid Composite / Designed & manufactured in EUROPE / Think Link® suspension system, 140 mm rear travel, integrated removable battery, 1. 8“ tapered HT, post mount 203 mm, mullet 29" / 27. 5"+ wheelset, 12x148 mm Boost thru axle
Silnik: SHIMANO EP8, 85 Nm, 36 V
Akumulator:
KELLYS Re-Charge K1 Li-ion internal removable 725 Wh / capacity 20 Ah, co-developed by KELLYS-BMZ
Wyświetlacz licznika: SHIMANO SC-E5003 cycle computer with assist switch
Widelec: ROCK SHOX 35 GOLD RL (29") Boost, 150 mm, DebonAir / Motion Control / Maxle Stealth 15 mm thru axle
Amortyzator tył: ROCK SHOX Deluxe Select R, DebonAir (210x55 mm)
Korby: SHIMANO EM600 / CRE70-B (34T) - length 170 mm
Przerzutka tył:
SHIMANO Deore XT Linkglide M8130 (direct mount)
Manetki: SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV)
Ilość biegów: 11
Kaseta: SHIMANO Linkglide CS-LG600-11 (11-50T)
Łańcuch: SHIMANO Linkglide CN-LG500 (122 links)
Hamulce:
SHIMANO MT420 Hydraulic Disc
Dźwignie hamulcowe: SHIMANO Deore BL-M4100
Tarcze hamulcowe: 203 mm front / 203 mm rear
Piasty: SHIMANO MT400-B Disc Center Lock (32 holes)
Obręcze: KLS Bender Disc (622x38 front / 584x38 rear / 32 holes)
Szprychy:
stainless steel black
Opona przednia: SCHWALBE Nobby Nic Performance 65-622 (29"x2.60) ADDIX
Opona tylna: SCHWALBE Nobby Nic Performance 70-584 (27.5"x2.80) ADDIX
Stery: ACROS 1. 8 semi-integrated tapered
Oś thru axle:
ROCK SHOX Maxle Stealth 15x110 mm front / Mr. control 12x177 mm rear
Wspornik kierownicy: KLS Alm/En 50 - diam 28. 6 mm / bar bore 31. 8 mm / length 60 mm
Kierownica:
KLS Alm/En 70 RiseBar - diam 31. 8 mm / rise 25 mm / width 760 mm
Chwyty: KLS Poison OneLockon
Sztyca: LIMOTEC A1 Remote Telescopic - diam 30. 9 mm / length 445 mm, travel 150 mm
Siodło:
fi’zi: k Taiga, S-alloy rails
Pedały: plastic
Rozmiary ram: M / L
